Anchorage, Implants
and Extra-Oral Products
Spider
K1 Ø1.5mm
Tapered Thread (Self-drilling/Self-tapping)
Available in 6.5, 8 and 10mm lengths.
The Spider Screw - K1 is self–drilling, due to the design of
the tapered thread, drilling is eliminated in most areas of the
mouth. In areas of high bone density, it may be necessary to
utilize the 1.1mm drill provided to penetrate the cortical plate.
Available in the following versions:
LONG NECK - elongated neck height (2mm) for areas of thick
tissue (Posterior and lateral areas).
SHORT NECK - standard neck height (1mm) for areas of thin
tissue (Anterior and lateral areas).
Long Neck - 2.0mm
O/No
Ø 1.5 x 6.5mm
7SCL-1506
Ø 1.5 x 8.0mm
7SCL-1508
Ø 1.5 x 10mm
7SCL-1510
Short Neck - 1.0mm
Ø 1.5 x 6.5mm
7SCR-1506
Ø 1.5 x 8.0mm
7SCR-1508
Ø 1.5 x 10mm
7SCR-1510
Multiple Purchase Discounts Available
Screws sold individually
Spider
K2 Ø1.9mm
Tapered Thread (Self-drilling/Self-tapping)
Available in 6, 7, 9 and 11mm lengths.
The Spider Screw - K2 is self–drilling, due to the design of the
tapered thread, drilling is eliminated in most areas of the mouth.
In areas of high bone density, it may be necessary to utilize the
1.3mm drill provided to penetrate the cortical plate. The 6mm
lengths screw can be placed in the palate or in areas where the bone
thickness is reduced. Available in the following versions:
LONG NECK - elongated neck height (2 mm) for areas of thick tissue
(Posterior and lateral areas).
SHORT NECK - standard neck height (1 mm) for areas of thin tissue
(Anterior and lateral areas).
Long Neck - 2.0mm
O/No
Ø 1.9 x 6.0mm
7SCL-1906
Ø 1.9 x 7.0mm
7SCL-1907
Ø 1.9 x 9.0mm
7SCL-1909
Ø 1.9 x 11.0mm
7SCL-1911
Short Neck - 1.0mm
Ø 1.9 x 6.0mm
7SCR-1906
Ø 1.9 x 7.0mm
7SCR-1907
Ø 1.9 x 9.0mm
7SCR-1909
Ø 1.9 x 11.0mm
7SCR-1911
Multiple Purchase Discounts Available
Screws sold individually
Spider K2 Ø2mm Regular Plus
Tapered Thread (self-drilling/self-tapping)
Spider Regular Plus - Allows further possibilities of application related to normal K2 Spider Screw.
Besides providing anchorage, it can be inserted vertically in edentulous areas to support an abutment
for temporary prosthesis. The acrylic resin abutment is mouldable and it can be fixed to the head of this
screw by a micro-screw. It is possible, after sand-blasting, to bond a bracket to the abutment.
No need for further instruments: the head dimension and geometry of this screw are the same as K2 screw.
O/No
Regular Plus 2.0 x 7.0mm
7SSP-2007
Regular Plus 2.0 x 9.0mm
7SSP-2009
Regular Plus 2.0 x 11.0mm
7SSP-2011
