Anchorage, Implants
and Extra-Oral Products
Spider Self-Ligating
K1 Ø1.5mm
Conical Thread (Self-Tapping/Self Drilling)
Available in 6.5, 8 and 10mm lengths.
The Spider Screw Self-Ligating TAD - K1 is
self-drilling and self-tapping. Due to the design
of the conical thread, drilling is eliminated in most
areas of the mouth. In areas of high bone density,
it may be necessary to utilize the 1.1mm drill
provided to penetrate the cortical plate. During
insertion of the Spider K1 do not exceed 20 Ncm.
O/No
Ø1.5 x 6.5mm
7SXL-1506
Ø1.5 x 8.0mm
7SXL-1508
Ø1.5 x 10.0mm
7SXL-1510
Spider Self-Ligating
K2 Ø1.9mm
Conical Thread (Self-Tapping/Self Drilling)
Available in 6, 7, 9 and 11mm lengths.
The Spider Screw Self-Ligating TAD- K2 is self-drilling and
self-tapping. Due to the design of the conical thread, drilling
is eliminated in most areas of the mouth. In areas of high bone
density, it may be necessary to utilize the 1.3mm drill provided
to penetrate the cortical plate. During insertion of the Spider
K2 do not exceed 30 Ncm.
O/No
Ø1.9 x 6.0mm
7SXL-1906
Ø1.9 x 7.0mm
7SXL-1907
Ø1.9 x 9.0mm
7SXL-1909
Ø1.9 x 11.0mm
7SXL-1911
Spider Screw
®
Self-Ligating K1, K2 Plus Starter Kit
Entire Kit can be sterilised
•
Autoclavable up to 273
o
F/134
o
C
•
Heat sterilisable up to 356
o
F/180
o
C
•
Chemiclavable up to 297
o
F/132
o
C
O/No
7CSS-6008
Kit Organiser contains:
1 x Ø1.1mm x 8.0mm Drill K1
O/No
7FSC-1108
1 x Ø1.3mm x 9.0mm Drill K2
O/No
7FSC-1309
1 x Contra Angle Pick-up Driver Short
O/No
7DPQ-3420
1 x Contra Angle Pick-up Driver Long
O/No
7DPQ-3425
1 x Contra Angle Driver TAD Key
O/No
7DLM-3134
1 x Self-Ligating TAD Key
O/No
7DXL-2820
1 x Handle Square Driver
O/No
7DSQ-3424
1 x Pick-up Driver Shaft
O/No
7DSP-5652S
1 x Screw Driver Body
O/No
7DSX-1690S
