Laboratory Products
Fan Type Screw
For symmetrical expansion of the maxilla.
The fan-like opening enables lateral
expansion of maxillary anteriors.
Expansion 6.0mm
1/1 Revolution 0.8mm
1/4 Revolution 0.02mm
O/No
1019 FA
Piston Screws
For individual adjustment of single teeth. Method:
a knurled nut is screwed onto the assembly screw
2009 and positioned in the model with fixing
wax. After elaborating the base, the assembly
screw is removed and the thread is reworked with
the thread cutter. The length of the piston spring
depends on the desired regulation distance.
Piston Screw Starter Kit
2014
Contains:
Qty O/No
4mm Piston Screws
5
2004
6mm Piston Screws
5
2006
8mm Piston Screws
5
2008
Holding Screws
5
2009
Serrated Housing
10
2010
Reamer
1
2012
Screwdriver
1
2013
Rapid Expansion Screws
Palatal Suture Expansion Screws. Extremely robust special screws for
palatine suture expansion. The anatomically designed shape minimises
space requirements in the palate. Pre-formed, laser-welded retention
arms, stable guiding pins and generously dimensioned threaded spindle
for the greatest possible safety and force transmission. Integrated
synthetic bush for reverse rotation protection. Pleasantly easy to
operate while offering the highest reliability. The fixed centrepiece (not
in 1114/10) guarantees maximal torsional and flexural rigidity when
expanded. Supplied with safety key.
Expansion 5.0mm
1/1 Revolution 0.9mm
1/4 Revolution 0.225mm
O/No
1114/10
Expansion 9.0mm
1/1 Revolution 0.9mm
1/4 Revolution 0.225mm
O/No
1114/13
Expansion 11.0mm
1/1 Revolution 0.9mm
1/4 Revolution 0.225mm
O/No
1114/15
Expansion 13.0mm
1/1 Revolution 0.9mm
1/4 Revolution 0.225mm
O/No
1114/17
