Interproximal Reduction
and Separation
Diamond Discs
Use Diamond discs for both separating and contouring.
Available single and double-sided.
Designed for use with a straight handpiece only. Autoclavable.
Coverage = (B)
Double Sided:
Size (B)
Thickness Max Speed O/No
14mm 2mm 0.15mm 25,000 rpm
9001-911H-140
18mm 3mm 0.20mm 25,000 rpm
9001-911H-180
22mm 3mm 0.20mm 20,000 rpm
9001-911H-220
Single Sided:
18mm 3mm 0.10mm 25,000 rpm
9001-911HH-180
(safe side out)
18mm 3mm 0.10mm 25,000 rpm
9001-911HV-180
(safe side in)
Flexible Serrated Diamond Discs
Used for anterior interproximal stripping. Available in two sizes
and are double sided. For use with a straight handpiece only,
and can be used with disc guards.
Autoclavable. Thickness 0.20mm Double Sided
Size Coverage (B)
Max Speed O/No
18mm 3mm
20,000 rpm
9001-53199
22mm 3mm
30,000 rpm
9001-53201
Disc Guard, Adapter
and E-Type Handpiece
For use with a straight handpiece, Disc Guards have visual access
windows for safety, and are available in two sizes. The Adapter allows
discs to attach to a straight handpiece. Autoclavable.
Size O/No
Large Disc Guard
22mm
9001-53202
Medium Disc Guard
18mm
9001-53200
Adapter for straight handpiece
9001-53203
Three piece set (one of each above)
9001-53299
E-Type straight handpiece
853-204
Now available Clear all-in-one adaptor unit, to allow full visual access
for safety.
Disposable - single use only, supplied 15 per bag.
Medium Disc Guard/Adaptor
18mm
9001-53200-DI
(B)
(B)
