Interproximal Reduction
and Separation
SpaceFile™ Interproximal Reduction (IPR) Files are precision
Swiss-made diamond-impregnated files that can accomplish
a wide range of tasks including breaking contact, reduction,
contouring, fine trimming and finishing.
Files can be used three ways, depending on your personal
preference and case requirements:
•
Hand-held
•
With removable grip for added control
•
With optional handpiece.
A Removable Grip is included in each starter assorted pack.
When this is used with a file, it provides better hand-held control,
resulting in a more precise reduction. Ventilation holes allow
low temperature operation and prevent clogging. All files are
available either single sided or double-sided.
All files are sold in packs of 8.
Files, grip and inner tray are autoclavable. Thicknesses are shown under each order number.
Double-Sided
Left Single-Sided Right Single-Sided
Starter Assorted Packs
9001-40034
9001-40034-LS
9001-40034-RS
Includes 1 of each file plus Serrated Contact Point Saw
Polishing File - Grey
9001-40035-G 9001-40035-LS-G 9001-40035-RS-G
Final step in tooth surface restoration
0.085mm
0.070mm
0.070mm
Finishing File - Purple
9001-40035-P
9001-40035-LS-P 9001-40035-RS-P
For finishing prior to final polish
0.110mm
0.100mm
0.100mm
XX Fine File - White 15 micron
9001-40035-W 9001-40035-LS-W 9001-40035-RS-W
Pre-polish and finish reduced areas
0.140mm
0.123mm
0.123mm
Also use as initial strip for excessive crowding
X Fine File - Yellow 25 micron
9001-40035-Y 9001-40035-LS-Y 9001-40035-RS-Y
Pre-polish stripped areas. Also use as initial strip for crowded cases 0.160mm
0.138mm
0.138mm
Fine File - Red 40 micron
9001-40035-R 9001-40035-LS-R 9001-40035-RS-R
Use to initiate reduction in crowded cases Also use to contour after reduction 0.270mm
0.180mm
0.180mm
Medium File - Blue 60 micron
9001-40035-BL
9001-40035-LS-BL 9001-40035-RS-BL
Use for reduction with some crowding or when some space exists
0.330mm
0.210mm
0.210mm
Smaller grain can achieve results before using Coarse strip
Coarse File - Green 90 micron
9001-40035-GR 9001-40035-LS-GR 9001-40035-RS-GR
Primary working strip for IPR. Also use to trim and contour
0.370mm
0.235mm
0.235mm
X Coarse File - Black 120 micron
9001-40035-BLK 9001-40035-LS-BLK 9001-40035-RS-BLK
Use for maximum reduction at start of IPR
0.490mm
0.290mm
0.290mm
Serrated Contact Point Saw - Use to break contact points on enamel, composite, amalgam, porcelain, gold
9001-40035-CS
NSK 4:1 speed reducing reciprocating Handpiece
9001-40021HP
